COMMON FEATURES 共同特性
Body material: stainless steel (1.4305 EN 10088/AISI 303) 阀体材质: 不锈钢 (1.4305 EN 10088/AISI 303)
Orifice material: stainless steel (1.4305 EN 10088/AISI 303) 端口材质: 不锈钢 (1.4305 EN 10088/AISI 303)
Operator material: stainless steel 操作器材质: 不锈钢
Protection class: IP 65 (with connector and gasket) 保护等级: IP65 (包括连接器和垫片)
OPTIONS 选项
Available with body thread connection 1/8" (e.g. code D398DVC), performance ratings remain the same as D399DVC.
可提供 1/8" 螺纹的阀体 (如型号 D398DVC), 性能与 D399DVC 相同.
NPT connection on request, minimum batch may be required (e.g. code RD399CVGN)
NPT 接口按要求提供，必须有zui小的起订量 (如型号 RD399CVGN)
D398/399
- FKM seal, NC FKM 密封, NCMedia:
water, oil, air and aggressive fluids 流体：水，油，空气和腐蚀液体
Media temperature: -10°C ÷ +130°C 流体温度: -10°C ÷ +130°C
Ambient temperature: -10°C ÷ +50°C 环境温度: -10°C ÷ +50°C
Seal material: foodgrade FKM 密封材质: 食用 FKM
Coil power: AC 18va (holding 持续)
线圈功率: AC 36va (inrush 起动)
