TS系列智能热成像镜
384×288和640×512红外探测器具有出色的图像性能
Picatinny支架，可快速轻松拆卸
体积小、重量轻，集成良好
低功耗实现超长的工作时间
适合夜间户外和狩猎探险
|
SPECIFICATIONS |
||
|
Models |
TS3 |
TS6 |
|
Detector Type |
Uncooled Microbolometer |
|
|
Resolution |
384×288 |
640×512 |
|
Spectral Range |
8 μm ~ 14 μm |
|
|
Pitch Size |
12 μm |
|
|
Lens Focal Length |
35mm f1 /50mm f1 |
|
|
Focusing |
Manual |
|
|
Display Mode |
Color OLED, Monocular Viewfinder |
|
|
Image Patterns |
Black Hot/White Hot, customization available |
|
|
Power Supply |
Battery CR123A, 4 each |
|
|
Battery Life |
≥ 4 h |
|
|
Recognition Range |
≥ 800m, vehicle-size target; ≥ 400m, human |
|
|
Memory |
5000 snapshot images and 1 hr video recording |
|
|
Mounting Interface |
Picatinny mount |
|
|
Weight |
≤ 650 g (batteries included) |
|
|
Size (L ×W ×H) |
≤ 260mm ×60mm×80mm |
|
|
Electrical Interface |
Type-C |
|
|
Working Temperature |
-40 oC ~ + 55 oC |
|
|
Storage Temperature |
-55 oC ~ + 70 oC |
|
|
Optional Function (*) |
Laser Ranger Finder |
|
